DEUTZ Diesel Engines (for Construction Machinery)
This series of construction machinery diesel engines features an advanced Deutz V-engine with 214kW to 440kW power. The emission rating of this type of diesel motor is better than the Euro II standard.
With a rated RPM range of 1800-2100 RPM, these diesel machines can be used for a full variety of applications and conditions.
The engine adopts an inner oil-line and inner water channel structure that removes the need for external pipes that can cause problems. The service life is about 15,000 hours.
One-cylinder-one-head structure, good universality and convenient maintenance.
The inlet heating device allows the engine to start at temperatures as low as -35°C.
In addition to the characteristics of BFM1015 Technology, by improving the injection system, selecting Bosch EUP, this serie of engines can reach Eurolll, and the power is from 240 kW to 500 kW.
This series features a Deutz V-engine design with 6,8, 10 and 12-cylinder models. The power is a range of 102kW to 410kW. The one cylinder, single head structure does not require a cooling water circulation system.
The inlet heating device can help the engine start at temperatures as low as -35°C.
| Model | Intake Mode | Bore/Stroke(mm) | Displacement (L) | Rated Power (kW) | Rated Speed (r/min) | Max. Torque/Speed (N.m)/(r/min) | Min. Fuel Consumption (g/kw.h) | Idle Speed (rpm) | Dimension (mm) | Weight (kg) | Fuel System | Emission Level |
| BF6M1015 | Turbocharged | 132 ×145 | 11.906 | 223~240 | 1900/2100 | 1420/1300 | 209 | 600 | 1043×932×1174 | 850 | In-line Pump | National Ⅱ |
| Model | Intake Mode | Bore/Stroke(mm) | Displacement (L) | Rated Power (kW) | Rated Speed (r/min) | Max. Torque/Speed (N.m)/(r/min) | Min. Fuel Consumption (g/kw.h) | Idle Speed (rpm) | Dimension (mm) | Weight (kg) | Fuel System | Emission Level |
| BF6M1015C | Turbocharged Inter-cooled |
132 ×145 | 11.906 | 273~300 | 1900/2100 | 1978/1200 | 200 | 600 | 1043×932×1174 | 850 | In-line Pump | National Ⅱ |
| Model | Intake Mode | Bore/Stroke(mm) | Displacement (L) | Rated Power (kW) | Rated Speed (r/min) | Max. Torque/Speed (N.m)/(r/min) | Min. Fuel Consumption (g/kw.h) | Idle Speed (rpm) | Dimension (mm) | Weight (kg) | Fuel System | Emission Level |
| BF6M1015CP | Turbocharged Inter-cooled | 132 ×145 | 11.906 | 300~330 | 1900/2100 | 1876/1300 | 202 | 600 | 1043×932×1174 | 850 | In-line Pump | National Ⅱ |
| Model | Intake Mode | Bore/Stroke(mm) | Displacement (L) | Rated Power (kW) | Rated Speed (r/min) | Max. Torque/Speed (N.m)/(r/min) | Min. Fuel Consumption (g/kw.h) | Idle Speed (rpm) | Dimension (mm) | Weight (kg) | Fuel System | Emission Level |
| BF8M1015C | Turbocharged Inter-cooled | 132 ×145 | 15.874 | 364~400 | 1900/2100 | 2640/1200 | 200 | 600 | 1151×955×1174 | 1060 | In-line Pump | National Ⅱ |
| Model | Intake Mode | Bore/Stroke(mm) | Displacement (L) | Rated Power (kW) | Rated Speed (r/min) | Max. Torque/Speed (N.m)/(r/min) | Min. Fuel Consumption (g/kw.h) | Idle Speed (rpm) | Dimension (mm) | Weight (kg) | Fuel System | Emission Level |
| BF8M1015CP | Turbocharged Inter-cooled | 132 ×145 | 15.874 | 400~440 | 1900/2100 | 2500/1300 | 211 | 600 | 1151×955×1174 | 1060 | In-line Pump | National Ⅱ |
| Model | Intake Mode | Bore/Stroke(mm) | Displacement (L) | Rated Power (kW) | Rated Speed (r/min) | Max. Torque/Speed (N.m)/(r/min) | Min. Fuel Consumption (g/kw.h) | Idle Speed (rpm) | Dimension (mm) | Weight (kg) | Fuel System | Emission Level |
| TCD2015V06 | Turbocharged Inter-cooled | 132 ×145 | 11.906 | 240~360 | 2100 | 2080/1300 | 202 | 600 | 1077× 932×1141 | 1020 | Unit Pump | National Ⅲ |
| Model | Intake Mode | Bore/Stroke(mm) | Displacement (L) | Rated Power (kW) | Rated Speed (r/min) | Max. Torque/Speed (N.m)/(r/min) | Min. Fuel Consumption (g/kw.h) | Idle Speed (rpm) | Dimension (mm) | Weight (kg) | Fuel System | Emission Level |
| TCD2015V08 | Turbocharged Inter-cooled | 132 ×145 | 15.874 | 350~500 | 2100 | 2890/1400 | 208 | 600 | 1250×932×1172 | 1245 | Unit Pump | National Ⅲ |
| Model | Intake Mode | Bore/Stroke(mm) | Displacement (L) | Rated Power (kW) | Rated Speed (r/min) | Max. Torque/Speed (N.m)/(r/min) | Min. Fuel Consumption (g/kw.h) | Idle Speed (rpm) | Dimension (mm) | Weight (kg) | Fuel System | Emission Level |
| TCD12.0V6 | Turbocharged Inter-cooled | 132 ×145 | 11.906 | 240~390 | 2100 | 2130/1400 | 193 | 600 | 1140×945×1168 | 995 | High-Pressure Common Rail | National Ⅳ |
| Model | Intake Mode | Bore/Stroke(mm) | Displacement (L) | Rated Power (kW) | Rated Speed (r/min) | Max. Torque/Speed (N.m)/(r/min) | Min. Fuel Consumption (g/kw.h) | Idle Speed (rpm) | Dimension (mm) | Weight (kg) | Fuel System | Emission Level |
| TCD16.0V8 | Turbocharged Inter-cooled | 132 ×145 | 15.874 | 350~520 | 2100 | 2890/1400 | 199 | 600 | 1395×945×1196 | 1260 | High-Pressure Common Rail | National Ⅳ |
